含天然气水合物储层衰减岩石物理研究进展

刘涛; 包雪阳; 朱翔宇; 李安昱

doi:10.19975/j.dqyxx.2023-028

含天然气水合物储层衰减岩石物理研究进展

doi: 10.19975/j.dqyxx.2023-028

刘涛^1,,
包雪阳^{2, 1, 3, 4, ,},
朱翔宇⁵,
李安昱⁵

1.
南方科技大学地球与空间科学系，深圳 518055
2.
深圳市深远海油气勘探技术重点实验室（南方科技大学），深圳 518055
3.
南方海洋与工程广东省实验室（广州），广州 511458
4.
广东省地球物理高精度成像技术重点实验室（南方科技大学），深圳 518055
5.
中国地质大学（北京）地球物理与信息技术学院，北京 100083

基金项目: 国家自然科学基金资助项目（41976046）；南方海洋与工程广东省实验室（广州）人才团队引进重大专项资助项目（GML2019ZD0203）；广东省地球物理高精度成像技术重点实验室资助项目（2022B1212010002）；深圳市深远海油气勘探技术重点实验室项目（ZDSYS20190902093007855）；中国博士后科学基金项目（2021M701558）

详细信息

作者简介:
刘涛（1994-），男，博士研究生，主要从事天然气水合物的基础物性研究. E-mail：jmjm201201@163.com

通讯作者:
包雪阳（1979-），男，助理教授（副研究员），主要从事地球物理成像反演的理论与应用研究. E-mail：baoxy@sustech.edu.cn

中图分类号: P631
计量
- 文章访问数: 59
- HTML全文浏览量: 24
- PDF下载量: 20
- 被引次数: 0
出版历程
- 收稿日期: 2023-05-31
- 修回日期: 2023-07-18
- 录用日期: 2023-07-25
- 网络出版日期: 2023-08-02

Review of rock-physics studies on natural gas hydrate-bearing sediment attenuation

Liu Tao^1
,,
Bao Xueyang^{2, 1, 3, 4
, ,},
Zhu Xiangyu⁵,
Li Anyu⁵

1.
Department of Space Sciences, Southern University of Science and Technology, Shenzhen 518055, China
2.
Shenzhen Key Laboratory of Deep Offshore Oil and Gas Exploration Technology, Southern University of Science and Technology, Shenzhen 518055, China
3.
Southern Marine Science and Engineering Guangdong Laboratory (Guangzhou), Guangzhou 511458, China
4.
Guangdong Provincial Key Laboratory of Geophysical High-resolution Imaging Technology, Southern University of Science and Technology, Shenzhen 518055, China
5.
School of Geophysics and Information Technology, China University of Geosciences (Beijing), Beijing 100083, China

Funds: Supported by the National Natural Science Foundation of China (Grant No. 41976046), the Key Special Project for Introduced Talents Team of Southern Marine Science and Engineering Guangdong (Guangzhou) (Grant No. GML2019ZD0203), Guangdong Provincial Key Laboratory of Geophysical High-resolution Imaging Technology (Grant No. 2022B1212010002), Shenzhen Key Laboratory of Deep Offshore Oil and Gas Exploration Technology (Grant No. ZDSYS20190902093007855), and China Postdoctoral Science Foundation (Grant No. 2021M701558)

摘要

摘要: 衰减是储层的重要基础物性，正确认识天然气水合物储层的吸收衰减机制对于准确预测水合物饱和度具有重要意义. 天然气水合物以不同形态赋存在粗粒砂岩或细粒黏土质沉积物中，而这两种水合物储层对应的衰减特征存在显著差异. 为了阐明其内部的衰减机理，近年来学者们提出了多种岩石物理模型. 其中，砂岩水合物层的衰减模型大致有两类，其中一类以三相Biot理论为基础，模型中包含多种描述水合物颗粒与砂岩颗粒间接触作用的衰减机制，如颗粒胶结、摩擦、微裂隙导致的喷射流等. 这类模型可以较合理地再现实际声波测井资料中衰减随水合物饱和度增加而增加的情况，但在地震频段无法产生有效的衰减强度. 另一类模型的衰减主要以等效颗粒模型所描述的水合物内部孔隙水与自由孔隙水之间的交换作用为主导，其能够解释砂岩水合物在地震频段的衰减现象. 黏土质沉积物中的水合物衰减研究则是首先基于等效颗粒模型模拟黏土矿物附着水的衰减机制建立背景沉积物的衰减模型；接着在其基础上通过量化纯水合物的物性和水合物赋存对背景沉积物性质的改变来完成建模. 该模型也已成功应用于地震频段的反射地震资料中. 以上衰减模型的提出使水合物的衰减研究取得了实质性进展，使研究人员能够定量化分析观测资料中的衰减现象，并通过衰减约束水合物饱和度. 然而这些模型的应用仍存在不同程度的限制：研究发现砂岩水合物储层的衰减模型无法匹配实际资料中观测到的横波衰减强度；以及黏土质水合物储层衰减模型缺少对裂隙参数的表征，在声波频段的模型结果有待验证. 为了提升模型的预测精度和应用范围，未来需对水合物赋存形态与衰减的关系加深理解，结合更多实际资料进一步深入细致地开展岩石物理研究.
- 天然气水合物 /
- 衰减属性 /
- 岩石物理 /
- 水合物赋存形态
Abstract: Attenuation is an essential reservoir property, and understanding its mechanism in gas hydrate-bearing sediments is important for predicting gas hydrate saturation. Natural gas hydrates mainly accumulate in coarse-grained sands or fine-grained clays with different morphologies, and the attenuation characteristics of these gas hydrate-bearing sediments are inconsistent. Many rock-physics models have been proposed in recent years to elucidate the attenuation mechanisms of gas hydrate occurrence. There are two types of attenuation models for gas hydrates in sands. One of these models is based on the three-phase Biot theory and contains multiple mechanisms that describe the contact effects between hydrate and sediment grains, such as grain cementation and squirt flows caused by microcracks. This model can reasonably reproduce the enhanced attenuation observed with increasing hydrate saturation in sonic-logging data. Attenuation described in the effective grain model is dominated by the viscous flow between the water in hydrate pores and free water. These types of models agree with the seismic attenuation observed in gas hydrates in sands. Moreover, the attenuation model of gas hydrates in clay is formulated by first establishing an attenuation model for background sediments, which employs the effective grain model to characterize attenuation in clay minerals; then, the properties of pure gas hydrate and the effects of hydrate occurrence on sediments are quantified. This model has also been successfully applied to seismic reflection data in the seismic frequency band. The above models have achieved significant progress in attenuation studies on gas hydrate-bearing sediments, and they have aided the quantitative interpretation of observed attenuation in field data and attenuation-related constraints for gas hydrate saturation. However, the application of these models is limited to certain extents: the attenuation predicted by the gas hydrate-bearing sands model failed to match that observed in the field data. Additionally, the gas hydrate-bearing clays model does not consider fracture shapes, and its performance has not been verified at the ultrasonic frequency band. To improve the accuracy and applicability of these models, the relationship between hydrate morphology and attenuation must be elucidated, and further rock-physics studies based on field data must be conducted.
- natural gas hydrate /
- attenuation property /
- rock physics /
- hydrate morphology

HTML全文

图 1 天然气水合物的全球分布图. 图中的红色标记代表确定的水合物赋存区域，黄色圆圈代表存在多种水合物识别标志的赋存区，星号代表仅存在BSR的区域（来源：美国地质调查局）

Figure 1. Global gas hydrate distribution. The red markers in the figure represent the confirmed gas hydrate-bearing areas; yellow circles are possible gas hydrate host areas; and blue stars represent where BSR-only exists (source form: USGS)

下载: 全尺寸图片幻灯片

图 2 水合物的赋存形态. （a）颗粒胶结；（b）孔隙充填；（c）骨架支撑；（d）水合物堵塞孔隙吼道；（e）毛细管捕获游离气；（f）水合物包裹游离气；（g）裂隙充填（修改自Ecker et al., 1998; 王秀娟等, 2023）

Figure 2. Gas hydrate morphologies. (a) Hydrate cementing grains; (b) Hydrate floating in pores; (c) Hydrate supporting sediment frame; (d) Hydrate blocking pore throat; (e) Pore throat capturing free gas; (f) Hydrate enveloping free gas; (g) Fracture-filling (modified from Ecker et al., 1998; Wang et al., 2023)

下载: 全尺寸图片幻灯片

图 3 不同模型的纵波衰减结果与加拿大马利克 5L-38井的声波测井数据（修改自Guerin and Goldberg, 2005）. 图中的数据点是基于观测数据计算的$ {Q}^{-1} $，不同的曲线代表不同衰减机制的叠加结果. 其中，水合物饱和度是从电阻率测井数据中计算得出的

Figure 3. P-wave attenuations predicted via different models and sonic-logging data at the Mallik 5L-38 site (modified from Guerin and Goldberg, 2005). Dots represent $ {Q}^{-1} $ calculated from observed data, and different types of lines indicate the theoretical $ {Q}^{-1} $. Gas hydrate saturation was calculated using resistivity well logs

下载: 全尺寸图片幻灯片

图 4 Best等（2013）的衰减模型结果与实验室人工合成水合物样品的纵波衰减测量结果. 不同的线型代表不同的水合物赋存形态对应的理论结果

Figure 4. Attenuation values predicted by Best et al. (2013) and measured from the synthetic hydrate samples in the laboratory. Different lines present the results of different hydrate morphologies

下载: 全尺寸图片幻灯片

图 5 Liu等（2022）模型的理论衰减随频率的变化情况. 不同的线型代表不同的水合物体积分数（$ {C}_{\mathrm{h}} $）

Figure 5. Theoretical attenuation vs. frequency predicted by the Liu et al. (2022) model. Different lines present the results of different hydrate concentrations ($ {C}_{\mathrm{h}} $)

下载: 全尺寸图片幻灯片

图 6 Liu等（2022）模型的理论衰减与印度克里希纳-哥达瓦里盆地地震反射数据实测衰减值的对比. 观测数据共有五组，分别来自不同的地震测线，用误差棒表示. 理论$ {Q}^{-1} $用不同标志表示

Figure 6. Comparisons between the attenuations predicted by the Liu et al. (2022) model and those determined from seismic reflection data in the Krishna-Godavari Basin in India. Five groups of field data from different seismic lines are marked using error bars. Theoretical $ {Q}^{-1} $ values are denoted using different markers

下载: 全尺寸图片幻灯片

表 1 含水合物区域的衰减案例

Table 1. Attenuation measurements in gas hydrate-bearing areas

地区	沉积物类型	数据频段	水合物对衰减的影响	来源
加拿大马利克	砂岩	声波测井	增强	Guerin and Goldberg, 2002, 2005
	砂岩	井间地震数据	增强	Bauer et al., 2005
	砂岩	垂直地震剖面	增强	Bellefleur et al., 2007
日本南海海槽	砂岩	声波测井	增强	Matsushima, 2005
日本南海海槽	砂岩	垂直地震剖面	无明显影响	Matsushima, 2006
美国墨西哥湾	砂岩	声波测井	增强	Wang et al., 2017
美国墨西哥湾	黏土质沉积物	声波测井	无明显影响	Wang et al., 2017
印度克里希纳-哥达瓦里盆地	黏土质沉积物	反射地震	减弱	Dewangan et al., 2014
印度克里希纳-哥达瓦里盆地	黏土质沉积物	反射地震	减弱	Jaiswal et al., 2012
印度科拉拉-康坎盆地	黏土质沉积物	反射地震	减弱	Sain et al., 2009
挪威斯瓦尔巴特群岛	黏土质沉积物	OBS&反射地震	减弱	Rossi et al., 2007; Westbrook et al., 2008
挪威斯瓦尔巴特群岛	黏土质沉积物	反射地震	减弱	Singhroha et al., 2016
美国布莱克岭	黏土质沉积物	反射地震	无明显影响	Wood et al., 2000
人工样品	砂岩	<400 Hz	增强，随水合物饱和度增加，衰减先增强后减弱	Priest et al., 2006
人工样品	砂岩	50～550 Hz	增强，随水合物饱和度增加，衰减先增强后减弱	Best et al., 2013

下载: 导出CSV
