A summary report on the Space Physics practical education in 2022
-
摘要: 空间科学与技术专业实践教育对于本科生空间物理学习具有重要意义. 近年来，中国科学技术大学地球和空间科学学院空间科学与技术专业基于国家大型空间环境地基综合监测系统——子午工程的链条观测优势，开展全方位、多角度的本科生暑期专业实践教育. 在实践教育中，老师们生动详实地为同学们讲解实习的各项内容，带领同学们学习观测数据的处理与分析，并且参观子午工程台站；同学们使用多种观测设备，学习了光学、无线电和磁场等不同探测技术，了解了不同探测仪器的探测原理，掌握了科研软件的使用方法，并可视化分析空间天气事件期间近地空间环境的变化特征. 最后，同学们还进行了实践教育总结汇报. 通过参加空间科学与技术专业实践教育，同学们真正接触科研工作，成功地克服了初次尝试科研时的“忐忑不安”，不仅提升了自主学习、小组分工合作等实践能力和科学素养，而且开阔了眼界，为更深入地了解空间物理学打下基础.Abstract: Hands-on education is of great importance for undergraduate students studying Space Physics. In recent years, the School of Earth and Space Sciences at the University of Science and Technology of China has conducted extensive undergraduate summer professional practical education based on the advantages of the Chinese Meridian Project's chain observation. Teachers guide students in learning about the processing and analysis of observation data, take them to the Chinese Meridian Project sites, and thoroughly explain to them the numerous facets of practical education. Students learn many detecting technologies, including optical, radio, and magnetic fields, as well as the concepts of various instruments used for detection, as well as how to use scientific data and research tools and visualize the change characteristics of the near-Earth space environment during space weather events through data analysis. Finally, the students conducted a summary report of their practical education. Through participating in space physics practical education, students truly engage in scientific research, successfully overcoming the "anxiety" of initial attempts at scientific research. This not only improves their practical abilities and scientific literacy such as independent learning and teamwork but also broadens their horizons and establishes a foundation for further understanding of Space Physics.
-
Key words:
- practical education /
- Space Physics /
- Meridian Project
-
图 2 通过GNSS信号获取电离层斜向TEC的处理流程是：基于原始RINEX文件计算伪距TEC和相位TEC，得到斜向TEC的基本形态，再通过去除野点和周跳，获得电离层斜向TEC变化. （a, b）表示一个弧段去除野点和周跳前后斜向TEC结果；（c, d）表示PIMO站（14.6°N,121.1°E）在2022年2月1日观测的去除野点和周跳前后的斜向TEC变化
Figure 2. The processing flow for obtaining slant TEC from GNSS signals is as follows: Based on the original RINEX file, the pseudo-range TEC and phase TEC is used to obtain slant TEC. (a, b) Show one arc before or after outliers and cycle slips are removed. (c, d) Show the changes in slant TEC observed by the PIMO station (14.6°N, 121.1°E) on the whole day, February 1, 2022 before and after eliminating outliers and cycle slips
图 3 SDO卫星于2022年1月31日23:59:59 UT至2月1日00:00:09 UT观测的不同波段日面图像. (a-f) 分别为94 Å、335 Å、193 Å、304 Å、131 Å、171 Å波段
Figure 3. Images of solar disk at different bands observed by the SDO satellite from 23:59:59 UT on January 31 to 00:00:09 UT on February 1, 2022. Panels (a) to (f) show the images in the 94 Å, 335 Å, 193 Å, 304 Å, 131 Å and 171 Å wavelength bands, respectively
图 4 2022年2月1—8日期间Kp、Ap、Dst和F10.7指数随时间的变化
Figure 4. Variations in Kp, Ap, Dst, and F10.7 indices during February 1-8, 2022
图 5 2022年2月1—8日期间北京、乐东、漠河三站地磁场H分量随时间的变化
Figure 5. Variation of H component of the geomagnetic field at Beijing, Ledong, and Mohe stations during February 1-8, 2022
图 6 2022年2月1—8日期间漠河站电离层测高仪观测的foF2、hmF2和TEC随时间的变化
Figure 6. Variations of foF2, hmF2, and TEC observed by the ionosonde at Mohe Station with time during February 1-8, 2022
图 7 2022年2月1—8日期间4个不同台站观测到的北斗地球同步轨道卫星（C03）TEC随时间的变化
Figure 7. TEC variations of Beidou geostationary satellite (C03) observed by 4 different stations during February 1-8, 2022
图 8 2022年2月1—8日期间漠河、北京、蒙城、武汉站流星雷达观测的纬向风场和经向风场随时间和高度的变化
Figure 8. Variation of zonal and meridional wind as a function of date and altitude observed by the meteor radars at Mohe, Beijing, Mengcheng, and Wuhan Stations during February 1-8, 2022
-
[1] Dang T, Li X, Luo B, et al. 2022. Unveiling the space weather during the Starlink satellites destruction event on 4 February 2022[J]. Space Weather, 20: e2022SW003152. https://doi.org/10.1029/2022SW003152. [2] Huang X, Reinisch B W. 1996. Vertical electron density profiles from the Digisonde network[J]. Advances in Space Research, 18(6): 121-129. https: //doi. org/https://doi.org/10.1016/0273-1177(95)00912-4. [3] 刘立波, 万卫星. 2014. 我国空间物理研究进展[J]. 地球物理学报, 57（11）: 3493-3501. Doi;10.6038/cig20141101. doi: 10.6038/cig20141101Liu L B, Wang W X. 2014. A brief overview on the issue on Space Physics and space weather[J]. Chinese Journal of Geophysics, 57(11): 3493-3501 (in Chinese). doi: 10.6038/cjg20141101. [4] 王赤, 冯学尚, 万卫星, 等. 2009. 东半球空间环境地基综合监测子午链简介[J]. 国际地震动态, 37（6）: 32-38Wang C, Feng X S, Wan W X, et al. 2009. The Meridian chain of comprehensive ground-based space environment monitors in the Eastern Hemisphere[J] Recent Developments in World Seismology, 37(6): 32-38 (in Chinese). [5] Wang C. 2010. New chains of space weather monitoring stations in China[J]. Space Weather, 8: S08001. [6] Wang C, Chen Z Q, Xu J Y. 2020. Introduction to Chinese Meridian Project –Phase II[J]. Chinese Journal of Space Science, 40(5): 718-722 doi: 10.11728/cjss2020.05.718 [7] 王赤, 陈志青, 胡连欢, 等. 2021. 我国空间环境天/地基监测平台的发展态势和展望[J]. 航天器环境工程, 38（3）: 225-239 doi: 10.12126/see.2021.03.001Wang C, Chen Z Q, Hu L H, et al. 2021. Development and prospect of China’s space-based and ground-based space environment monitoring platforms[J]. Spacecraft Environment Engineering, 38(3): 225-239(in Chinese). doi: 10.12126/see.2021.03.001 -
